White Dual Band Mesh Router / Mesh Network Router For Home Use 10/100/1000Mbps

Product Categories
Shenzhen Zhibotong Electronics Co., Ltd.
Contact Now

White Dual Band Mesh Router / Mesh Network Router For Home Use 10/100/1000Mbps

  • 1
  • 2

Brand Name : OEM/ZBT

Model Number : Mesh-L6

Certification : FCC,CE,ROSH

Place of Origin : China

MOQ : 1

Price : $31.5-37.5/pcs

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/week

Delivery Time : Sample order:3 days; Bulk order: 25-30 days

Packaging Details : 3pcs device/packing box

Color : White

wireless rate : 1200Mbps

Wire Speed : 10/100/1000Mbps

Interface : 1WAN+1LAN

Type : Wireless

Product Name : Gigabit Dual Band Mesh Router, Mesh Wifi Router, Mesh Router For Home Use

Contact Now

Gigabit Dual Band Mesh Router, Mesh Wifi Router, Mesh Router For Home Use


Product Feature

  • 1*Gigabit WAN port, 1*Gigabit LAN port
  • Dual Band, 1200Mbps wireless rate
  • Support Mesh Function, at least 3pcs/1 set
  • Preload English firmware

Gigabit Dual Band Mesh Router, Mesh Wifi Router, Mesh Router For Home Use

Product Description

ZBT-L6 is a Gigabit dual-band home wireless networking device. It has a 10/100/1000Mbps WAN/LAN adaptive port, a 10/100/1000Mbps adaptive LAN port, and a wireless transmission rate 1200Mbps.

Generally for mesh network, at least need 3pcs device will be mesh network. If you need one set (3pcs), we have suitable set already.

Gigabit Dual Band Mesh Router, Mesh Wifi Router, Mesh Router For Home Use


Product Specification

Product Name Gigabit Ethernet Port Mesh Router Remark
Product Type LAN uplink (compatible with WIFI uplink) device
Model ZBT-L6
WAN 1*10/100/1000M Auto MDI/MDIX WAN /LAN Port
LAN 1piece 10/100/1000M Auto MDI/MDIX LAN Port
WLAN 2.4G 300Mbps,5G 867Mbps
Hardware Main Chipset RTL8197FS-VE5
Main Frequency 1GHz
FLASH 16MByte SOP8
RAM 128MByte
Adapter 12V1A
LED 1*Integrated indicator (Red, Green, Yellow)
Button Reset
Antenna 2*3dBi internal antenna
Wireless Rate 1167Mbps
Wireless Protocol 802.11b/g/n 2.4GHz; 802.11ac/a/n 5GHz.
Wired Protocol 802.3；802.3u
MESH networking standard 802.11s
Roaming standard 802.11v/r
Type Demand item Specification





Wire Interface		 WAN 1*10/100/1000 Base-T Interface,IEEE802.3/802.3u,Support full-duplex / half-duplex flow control.
LAN 1*10/100/1000 Base-T Interface,IEEE802.3/802.3u,Support full-duplex / half-duplex flow control.



Power Interface

1*Power Interface, The router is powered by an external power adapter. The external power adapter should:

1. Meet the EMC requirements of YD/T 983 and pass CCC certification;

2. Input voltage: 198-242V ~ 50Hz;

3. Output voltage DC: 12V ± 5%, ripple range ± 200mV, output current: 1A;

4. The MTBF time of the power supply is: greater than 30,000 hours;

5. The power supply interface of the device itself and the DC output interface of the power adapter should be a unified international standard circular interface with a DC head diameter of 2.1 mm;

6. The adapter's DC output power cord can be optionally equipped with an EMI absorption magnetic ring;

7. Under normal conditions, the insulation resistance between the metal casing of the equipment and the power line should be not less than 50MΩ.

8, should have lightning protection against surge test, lightning protection level of at least 1.5KV.


Wireless Interface

Wi-Fi Networking		 802.11b/g/n/ a/ac,2.4GHz/5GHz,Wireless rate 1167Mbps；
2* Internal 3dBi Omnidirectional dual frequency antenna.

The Current wifi Device quantity can highly reach to 40
FAQ

Can you printing Customer logo on products?

Yes, we can printing your logo on products.

Do you provide PCBA board order only?

Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.

Can you desin products as per customer's requirements?

Yes, of course. We have our own R&D department, we have ability to design and produce at same time.

Do you....?

Maybe, why don't contact us now! Inquring us to see if we can, or if we do, to see if we can suprise you!
